Integrated Oilfield Large Tank Gas Recovery System
■ Applicable Overall skid-mounted integrated system for recovery and utilization of volatile flash vapor from oil storage tanks in the oilfield.■ Features Customized as required Integrated skid-mounted
Operation safety, economy and environmental protection
|
Equipment Parameters
|
Treatment capacity
Nm3/D
|
Inlet pressure
（Mpa)
|
Exhaust pressure
（Mpa)
|
Motor power
KW
|
Overall dimensions
（mm)
|
|
DW-6/3 |
7000 |
Atmospheric pressure
|
0.30 |
45 |
6500*3000*3000 |
|
DW-4/3 |
6000 |
Atmospheric pressure
|
0.30 |
30 |
6500*3000*3000 |
|
VW-4.5/4.5 |
5000 |
Atmospheric pressure
|
0.45 |
37 |
6500*3000*3000 |
|
DW-5/4.5 |
6000 |
Atmospheric pressure
|
0.50 |
37 |
6500*3000*3000 |
|
DW-6.5/-0.12-3 |
8000 |
0.0 |
0.30 |
55 |
7500*3000*3001 |
|
DW-0.65/(3-4)-36 |
3000 |
0.3-0.4 |
3.60 |
30 |
6500*3000*3000 |
