Chemical unloading compressor
■ Applicable The chemical unloading series compressor is used for unloading, loading and residual liquid recovery of propylene and liquid ammonia; unloading, loading and residual liquid recovery of liquefied petroleum gas, dimethyl ether, butadiene and C4.
■ Features Compact structure and easy operation
Simple operation and maintenance, affordable
|
Equipment Parameters
|
Unloading capacity （T/h）
|
Inlet pressure （Mpa)
|
Exhaust pressure （Mpa)
|
Motor power KW
|
Overall dimensions （mm)
|
|
ZW-0.8/16-24 |
20 |
1.6 |
2.4 |
18.5 |
1000*600*900 |
|
ZW-1.0/16-24 |
30 |
1.6 |
2.4 |
22 |
1000*600*900 |
|
ZW-1.5/16-24 |
40 |
1.6 |
2.4 |
30 |
1500*1200*1000 |
|
ZW-2.0/16-24 |
60 |
1.6 |
2.4 |
37 |
1500*1200*1000 |
|
ZW-2.5/16-24 |
70 |
1.6 |
2.4 |
45 |
2000*1500*1200 |
|
VW-6.0/16-24 |
150 |
1.6 |
2.4 |
132 |
2800*2000*1600 |
|
ZW-0.8/10-16 |
20 |
1.0 |
1.6 |
11 |
1000*600*900 |
|
ZW-1.0/10-16 |
25 |
1.0 |
1.6 |
15 |
1000*600*900 |
|
ZW-1.5/10-16 |
35 |
1.0 |
1.6 |
22 |
1500*1200*1000 |
|
ZW-2.0/10-16 |
45 |
1.0 |
1.6 |
30 |
1500*1200*1000 |
|
ZW-2.5/10-16 |
55 |
1.0 |
1.6 |
37 |
2000*1500*1200 |
|
VW-5.0/10-16 |
110 |
1.0 |
1.6 |
75 |
2800*2000*1600 |
